Parametrics
According to different application scenarios and needs, you can choose to increase or reduce the number of modules to meet the energy storage needs of different scales and capacities
|
2 Battery Modules |
3 Battery Modules |
4 Battery Modules |
5 Battery Modules |
6 Battery Modules |
7 Battery Modules |
8 Battery Modules |
9 Battery Modules |
10 Battery Modules |
11 Battery Modules |
12 Battery Modules |
|
| Total Height | 885 mm | 1,125 mm | 1,365 mm | 1,605 mm | 1,125 mm | 1,231 mm | 1,365 mm | 1,471 mm | 1,605 mm | 1,231 mm | 1,365 mm |
| Total Weight | 115 Kg | 160 Kg | 205 Kg | 270 Kg | 315 Kg | 360 Kg | 405 Kg | 450 Kg | 495 Kg | 565 Kg | 605 Kg |
| Rated Voltage | 102V | 154V | 205V | 256V | 307V | 358V | 410V | 461V | 512V | 563V | 615V |
| Total Capacity | 10,240Wh | 15,360Wh | 20,480Wh | 25,600Wh | 30,720Wh | 35,840Wh | 40,960Wh | 46,080Wh | 51,200Wh | 56,320Wh | 61,440Wh |
| Max Voltage | 117V | 175V | 234V | 292V | 350V | 409V | 467V | 526V | 584V | 642V | 701V |
| Min Voltage | 87V | 130V | 173V | 216V | 259V | 302V | 346V | 389V | 432V | 475V | 518V |
| Output Wattage | 10.2kW | 15.4kW | 20.5kW | 25.6kW | 30.7kW | 35.8kW | 40.9kW | 46.1kW | 51.2kW | 56.3kW | 61.4kW |
