W1 Wall-mounted LI-ION BATTERY 51.2V 200AH(Copy)
- Robust and Reliable Energy Storage: The Voltsmile W1 Wall-Mounting Lithium Iron Battery Pack is the ultimate solution for robust and reliable energy storage needs.
- High Voltage and Capacity: Operating at 51.2V with a substantial capacity of 10.24kWh, the Voltsmile W1 ensures a dependable power supply for various applications.
- Indoor and Outdoor Versatility: Designed for both indoor and outdoor applications, the Voltsmile W1 offers flexibility in energy storage solutions.
- Durable and Weather-Resistant: With an IP67 rating, the Voltsmile W1 is built to withstand the elements, making it ideal for outdoor installations and ensuring reliable power supply in all conditions.
| Battery Chemistry | LiFePO4 |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 43.2~57.6V |
| Capacity | 10,240Wh |
| Charging Current | 100A |
| Discharging Current | 100A |
| Communications | CAN / RS485 |
| Scalability | Max 16 units in parallel |
| Dimensions | 888 x 518 x 150mm |
| Weight | 90 kg |
| Working Temp | 0° C~50° C |
| Store Temp | -20° C~55° C |
| IP Rating | IP67 |
| Humidity | 5%~95%(RH) No Condensation |
| Altitude | < 3500 M |
| Installation | Wall-Mounted |
| Warranty | 10 Years |
| Designed Life | 10 years+ |
| Certifications | IEC62619 / UN38.3 / CE / ROHS |
